Bơm trục vít phòng nổ BNA (110m3/giờ) Model: BNA
Hãng: Seepex-Đức
* Công nghiệp: Oil & Gas
* Đáp ứng tiêu chuẩn API 676 & API 682
* Lưu lượng: 0.3 ~ 110 m³/giờ
* Chứng chỉ phòng nổ: ATEX Directive 94 / 9 / EC
Tính năng Bơm trục vít phòng nổ BNA (110m3/giờ)
Low Shear
Gentle low shear pumping action. Oil and water mixtures must be transported with the least damage
to the oil droplet size to minimize risk of creating emulsions that are hard to separate. The Society of Petroleum Engineers (SPE) paper 18204 confirm that progressive cavity pumps are the best pump technology for oil / water separation.
Self Priming and No gas locking
Excellent self-priming characteristics and suction lift capabilities, even on gaseous liquids, up to 9m
Handling of multiphase products
Oil, water and gas are transported reliably by our uniquely configured pumps with control systems to
deal with variable flow requirements. Our pumps can be configured to handle up to a 99% gas content.
Solids Handling
Our pumps handle products with entrained solids. Drill cuttings and sand, for example, are handled with low
internal velocities.
Low NPSH Requirements
The NPSH requirement of our pumps is as low as 0.3m. This is ideal for liquids with elevated temperatures and high vapor pressures.
Viscosity is not a limitation
From low viscosity condensates to heavily dewatered oily sludge cake, our pumps never give up. With open
hopper designs non-flowable products are moved into the rotor / stator pumping elements.
Stable and variable flow
Our pumps deliver accurate metered flow with every revolution of the rotor. Flow rate variation is minimal
even across broad pressure ranges. Flow rates are directly proportional to pump speed.
Minimal Pulsation
The flow rate has minimal pulsation, so there is no need for pulsation dampeners.
Versatile
Integration of a SEEPEX pump is easy. They can be installed horizontally, vertically, in a can or fully
submerged, to fit the space available. Pump flow is reversible depending upon the process requirements.
High Pressures
SEEPEX pumps are unique because of our special universal joint construction. We can easily handle
suction pressures up to 150 bar (2180 psi) with both our pin and cardan-type universal joints.
Ứng dụng
Upstream Exploration
• Drilling mud transfer
• Cuttings Transfer
• Sewage removal and treatment
• Produced water treatment
• Fracking water
• Fracking chemicals production
Upstream Production
• Open / closed drains and Knockout drum drains
• Reject oil
• Lact/ oil transfer
• Polymer dosing
• Multiphase pumping
• MEG / TEG catalyst slurry
• Sewage maceration and pumping
• Gray water
• Produced fluid pumping
• Caisson emptying
Downstream
• Open / closed drains and Knockout drum drains
• Catalyst injection
• Polymer dosing
• Reject oil
• MEG / TEG
• Condensate
• Waste water
